Check Out Sparkle Power (SPI) FSP250-50PLB 250W Flex-ATX12V RoHS Power Supply OEM SKU: FSP250-50PLB

Sparkle Power (SPI) FSP250-50PLB 250W Flex-ATX12V RoHS Power Supply OEM SKU: FSP250-50PLB Best

Rate This Product :

Sparkle Power (SPI) FSP250-50PLB 250W Flex-ATX12V RoHS Power Supply OEM SKU: FSP250-50PLB Feature

• Complies with Flex ATX and ATX12V standard
• Noise Killer (Thermal fan speed control function)
• High efficiency and reliability
• Remote On/Off function
• Internal 12V DC fan included

Sparkle Power (SPI) FSP250-50PLB 250W Flex-ATX12V RoHS Power Supply OEM SKU: FSP250-50PLB Overview

P/N: FSP250-50PLB / 9PA2508102 Complies with Flex ATX and ATX12V standard Active Power Factor Correction Meeting with EN61000-3-2 High efficiency and reliability Remote On/Off function Internal 12V DC fan included Noise Killer (Thermal fan speed control function) Low noise and ripple Complies with FCC part 15 subpart J Class B and CISPR 22 Class B Output over voltage, short circuit, and over current protection 100% Hi-pot, ATE, and burn-in tested Re-settable power shut down Approved by UL 60950, CSA C22.2 No.234 Level 3, TUV EN60950, NEMKO (CB Report), CE Temperature Range: Operating 0° C ~ +25° C on 250W output load or 0° C ~ +50° C on 220W output load ; storage & shipping -20° C ~ +80° C Humidity: 95% on operating and 95% on storage Dielectric Withstand: Input to frame ground 1800V AC for 1 second Efficiency: 68% at minimum measured at nominal AC main voltage and frequency with maximum load on all output Rise Time: Less than 20ms Hold-up Time: 17ms minimum at nominal input voltage Power Good Signal: Power on delay time 100 ms to 500 ms, off delay 1ms minimum (TTL and CMOS compatible) Leakage Current: Not exceed 0.75mA at 115V AC, 60Hz MTBF: 100,000 hours on maximum load at +25° C degree Output Voltage: +3.3V 18.0A, +5V 20.0A, +12V 16.0A, -12V 0.5A, +5Vsb 2.0A Dimensions (WxHxL): 81.5x40.5x190mm / 3.9x1.6x7.5 inches This power unit has (1) 20 pin ATX connector, (1) ATX12V connector, (3) peripheral power connectors, and (1) floppy drive connector.
